Siemens SINUMERIK 828D - Milling; Face Milling (CYCLE61)

Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
431
9.4
Milling
9.4.1
Face milling (CYCLE61)
Function
You can face mill any workpiece with the "Face milling" cycle.
A rectangular surface is always machined. The rectangle is obtained from corner points 1
and 2 - which for a ShopTurn program - are pre-assigned with the values of the blank part
dimensions from the program header.
Workpieces with and without limits can be face-milled.
Clamping the spindle
For ShopTurn, the "Clamp spindle" function can be set up by the machine manufacturer.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
See also
Clamping the spindle (Page 247)
Approach/retraction
1. For vertical machining, the starting point is always at the top or bottom. For horizontal
machining, it is at the left or right.
The starting point is marked in the help display.
2. Machining is performed from the outside to the inside.
Machining type
The cycle makes a distinction between roughing and finishing:
● Roughing:
Milling the surface
Tool turns above the workpiece edge
● Finishing:
Milling the surface once
Tool turns at safety distance in the X/Y plane
Retraction of milling cutter
