Programming technology functions (cycles)

9.7 Additional cycles and functions in ShopTurn

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

583

9.7.4

Translation

For each axis, you can program an offset of the zero point.

New offset

Additive offset

Parameters

Description

Unit

Offset

• New

New offset

• Additive

Additive offset

Z

Offset Z

mm

X

Offset X

mm

Y

Offset Y

mm
