20.4 Long-term measurement of the energy consumption
Turning
862 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
20.4
Long-term measurement of the energy consumption
The long-term measurement of energy consumption is performed in the PLC and saved. The
values from times in which the HMI is not active are also recorded.
Measured values
The infeed and regenerative power values as well as the sum of the power are displayed for
the following periods:
● Current and previous day
● Current and previous month
● Current and previous year
Precondition
SENTRON PAC is connected.
Procedure
1.
The "Ctrl
-E Analysis" window is open.
2.
Press the "Long
-term measurement" softkey.
The "SINUMERIK Ctrl
-Energy Analysis Long-term Measurement" win-
dow opens.
The results of the long-term measurement are displayed.
4.
Press the "Back" softkey to terminate the long
-term measurement.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
