13.17 Setup data
Turning
776 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
13.17
Setup data
13.17.1
Backing up setup data
Apart from programs, you can also save tool data and zero point settings.
You can use this option, for example, to back up tools and zero point data for a specific
machining step program. If you want to execute this program at a later point in time, you will
then have quick access to the relevant settings.
Even tool data that you have measured on an external tool setting station can be copied
easily into the tool management system using this option.
Backing-up job lists
If you wish to backup a job list, which contains ShopTurn and G code programs, you obtain
dedicated selection boxes to backup the tool data and zero points.
Note
Backing up setup data from part programs
Setup data from part programs can
only be backed up if they have been saved in the
"Workpieces" directory.
For part programs, which are located in the "Part programs" directory, "Save setup data" is
not listed.
Backing up data
Data
Tool data
• No
• All used in the program (only for ShopTurn program and job list only
with ShopTurn programs)
• Complete tool list
Tool data for ShopTurn
programs
--
only available for job list
with ShopTurn and G
code programs
• No
• All used in the program
• Complete tool list
Tool data for G code
programs
-- only available for job list
with ShopTurn and G
code programs
• No
• Complete tool list
Magazine assignment
• Yes
• No
