Programming technology functions (cycles)
9.3 Contour turning
Turning
412 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
PL (only for G
Machining plane
With subsequent residual material removal
SC (only for G
Safety clearance x
Selection Always round on the contour
Uniform cut segmentation
Constant cutting depth
Continuous cut - (only for ∇)
Set machining area
Set machining area limits No
Machine relief cuts (grayed out)
Please refer to the machine manufacturer's specifications.
Stock removal rest (CYCLE952)
Function
Using the "Stock removal residual" function, you remove material that has remained for stock
removal along the contour.
During stock removal along the contour, the cycle automatically detects any residual material
and generates an updated blank contour. for ShopTurn, the updated unmachined-part
contour is automatically generated. For a C code program, for stock removal residual
material, "Yes" must be programmed. Material that remains as part of the finishing allowance
is not residual material. Using the "Stock removal residual material" function, you can
remove unwanted material with a suitable tool.
For stock removal of residual material, you require the option "residual mater
i-
al detection and machining".
