Tool management
12.8 Magazine
Turning
704 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
You can position magazine locations directly on the loading point.
The magazine list is opened.
Place the cursor on the magazine location that you want to position
onto the load point.
Press the "Position magazine" softkey.
The magazine location is positioned on the loading point.
If you have configured several loading points for a magazine, then the "Load Point Selection"
window appears after pressing the "Position magazine" softkey.
Select the desired loading point in this window and confirm your selection with "OK" to
position the magazine location at the loading point.
Tools can be directly relocated within magazines to another magazine location, which means
that you do not have to unload tools from the magazine in order to load them into a different
location.
When you are relocating a tool, the application automatically suggests an empty location.
You may also directly specify an empty magazine location.
Please refer to the machine manufacturer's specifications.
The magazine list is opened.
Position the cursor on the tool that you wish to relocate to a different
magazine location.
Press the "Relocate" softkey.
The "... relocate from location ... to location ..." window is displayed. The
"Location" field is pre
-assigned with the number of the first empty mag-
