Programming technology functions (cycles)
9.1 Drilling
Turning
352 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
X0
C0
Y0
Z0
α0
α1
N
R
Positioning
(only for ShopTurn)
X coordinate of the reference point (abs)
Positioning angle for machining surface
Y coordinate of the reference point (abs)
Z coordinate of the reference point (abs)
Starting angle for first position referred to the Y axis.
Positive angle: Circle is rotated counter-clockwise.
Negative angle: Circle is rotated clockwise.
Incrementing angle
Number of positions
Radius
• Straight line: Next position is approached linearly in rapid traverse.
• Circular: Next position is approached along a circular path at the
feedrate defined in the machine data.
mm
Degrees
mm
mm
Degrees
Degrees
mm
Displaying and hiding positions
Function
You can hide any positions in the following position patterns:
● Position pattern line
● Position pattern grid
● Position pattern frame
● Full circle position pattern
● Pitch circle position pattern
The hidden positions are skipped when machining.
The programmed positions of the position pattern are shown as follows in the programming
graphic:
= displayed (position is shown as a cross)
= hidden (position shown as a circle)
You have the option of either displaying or hiding positions - by activating the checkbox in
the displayed position table either using the keyboard or mouse.
