Tool management
12.15 Working with multitool
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
725
12.15.4
Removing a tool from multitool
If the multitool was mechanically re-assigned (i.e. new tool were mounted), then old tools in
the tool list must be removed from the multitool.
To do this, the cursor is positioned at the line where the tool is located, which is to be
removed. When unloading, the tool is automatically saved in the tool list outside the
magazine in the NC memory.
Procedure
1.
The tool list is opened.
2.
Position the cursor on the tool that you would like to unload from
the multitool and press the "Unload" softkey.
- OR -
Position the cursor on the tool that you would like to remove and
delete from the multitoo
l and press the "delete tool" softkey.
12.15.5
Delete multitool
Procedure
1.
The tool list is op
ened.
2.
Position the cursor on the multitool that you wish to delete.
3.
Press the "Delete multitool" softkey.
The multitool with all of the tools that are located in it is deleted.
