Programming technology functions (cycles)

9.7 Additional cycles and functions in ShopTurn

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

585

9.7.6

Scaling

You can specify a scale factor for the active machining plane as well as for the tool axis. The

programmed coordinates are then multiplied by this factor.

New scaling

Additive scaling

Parameters

Description

Unit

Scaling

• New

New scaling

• Additive

Additive scaling

Scale factor ZX

Scale factor Y
