Collision avoidance (only 840D sl)
11.2 Set collision avoidance
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
667
11.2
Set collision avoidance
Using "Settings", you have the option of separately activating or deactivating the collision
monitoring for the Machine operating area (operating modes, AUTO, JOG and MDI)
separately for the machine and tools.
Using machine data, you define from which protection level the collision monitoring for the
machine or the tool can be activated or deactivated in the operating modes JOG/MDI or
AUTO.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Setting
Effect
JOG/MDI operating mode
Collision avoidance
They switch the collision monitoring for the operating modes JOG/MDI
completely on or off.
AUTO mode
Collision avoidance
They switch the collision monitoring for the operating mode AUTO
completely on or off.
JOG/MDI
Machine
If the collision monitoring for the JOG/MDI operating modes is activat-
ed, then as a minimum, the
machine protection areas are monitored.
The parameter cannot be changed.
AUTO
Machine
If the collision monitoring for the AUTO operating mode is activated,
then as a minimum, the
machine protection areas are monitored.
The parameter cannot be changed.
JOG/MDI
Tools
They switch the collision monitoring of the tool protection areas for the
operating modes JOG/MDI on or off.
AUTO
Tools
They switch the collision monitoring of the tool protection areas for the
operating mode AUTO on or off.
Procedure
1.
Select the "Machine" operating area.
2.
Select the "JOG", "MDI" or "AUTO" mode.
