Multi-channel machining
10.2 Multi-channel support
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
647
Procedure
1.
Select the "Program manager" operating area.
2.
Position the cursor on the required main program (*.mpf) or on a job list
(*.job).
3.
Press the ">>" and "Automat." block building" softkey.
You are prompted as to whether you want to automatically insert blocks
in the program.
4.
Press the "OK" softkey to confirm the conversion.
10.2.10.2
Editing a converted program
Precondition
You have used the "Automatic block formation" softkey to convert a program into a
structured program.
Procedure
1.
Ope
n a converted program.
Opening and closing blocks
2.
Press the ">>" and "View" softkeys.
3.
Press the "Open blocks" softkey.
All blocks on the first level are opened.
To open the blocks on the second level, press the "Open blocks" sof
t-
key again.
4.
Press the "Close blocks" softkey.
Opened blocks on the second level are closed.
To close the blocks on the
first level, press the "Close blocks" softkey
again.
Note
: If all blocks on the second level are closed, the blocks on the first
level are closed the first time the softkey is pressed.
