Programming technology functions (cycles)
9.1 Drilling
Turning
296 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Centering
• Diameter (centered with reference to the diameter)
The angle for the center drill entered in the tool list is applied.
• Tip (centered with reference to the depth)
The drill is inserted into the workpiece until the programmed insertion depth is reached.
∅ It is inserted into the workpiece until the diameter is correct. - (for diameter centering
mm
Z1
Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1. - (for tip centering only)
mm
DT
• Dwell time (at final drilling depth) in seconds
• Dwell time (at final drilling depth) in revolutions
s
rev
Drilling (CYCLE82)
Function
With the "Drilling" function, the tool drills with the programmed spindle speed and feedrate
down to the specified final drilling depth (shank or tip).
The tool is retracted after a programmed dwell time has elapsed.
For ShopTurn, the "Clamp spindle" function can be set up by the machine manufacturer.
Please refer to the machine manufacturer's specifications.
For simple machining operations, you have the option to reduce the wide variety of
parameters to the most important parameters using the "Input" selection field. In this "Input
simple" mode, the hidden parameters are allocated a fixed value that cannot be adjusted.
Various defined values can be pre
-assigned using setting data.
Please refer to the machine manufacturer's specifications.
If the workpiece programming requires it, you can display and change all of the parameters
using "Input complete".
