Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.1 Drilling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
297
See also
Clamping the spindle (Page 247)
Approach/retraction
1. The tool moves with G0 to safety clearance of the reference point.
2. The tool is inserted into the workpiece with G1 and the programmed feedrate F until it
reaches the programmed final depth Z1.
3. When a dwell time DT expires, the tool is retracted at rapid traverse G0 to the retraction
plane.
Procedure
1.
The part program or ShopTurn program to be processed has been cr
e-
ated and you are in the editor.
2.
Press the "Drilling" softkey.
3.
Press the "Drilling Reaming" softkey.
4.
Press the "Drilling" softkey.
The "Drilling" input window opens.
Parameters in the "Input complete" mode
G code program parameters
ShopTurn program parameters
Input
• Complete
PL
Machining plane
T
Tool name
RP
Retraction plane
mm
D
Cutting edge number
SC Safety clearance mm F
Feedrate mm/min
mm/rev
S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
