Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.1 Drilling
Turning
298 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Unit
Machining posi-
tion
(only for G
code)
• Single position
Drill hole at programmed position
• Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
Machining
surface
(only for Shop-
Turn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for Shop-
Turn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for Shop-
Turn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Drilling depth
• Shank (drilling depth in relation to the shank)
The drill is inserted into the workpiece until the drill shank reaches the value pro-
grammed for Z1. The angle entered in the tool list is taken into account.
• Tip (drilling depth in relation to the tip)
The drill is inserted into the workpiece until the drill tip reaches the value pro-
grammed for Z1.
Note:
If it is not possible to define an angle for the drill in the tool management, it will
not be possible to select tip or shank (always tip, 0 field)
Z1
Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1.
mm
Predrilling
• Yes
• No
ZA - (only for
predrilling "yes")
Predrilling depth (abs) or predrilling depth in relation to the reference point (inc) mm
FA - (only for
predrilling "yes")
Reduced predrilling feedrate as a percentage of the drilling feedrate
%
Predrilling feedrate (ShopMill) mm/min or
mm/rev
Predrilling feedrate (G code) Distance/min
or dis-
tance/rev

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
