9.1 Drilling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
299
Parameter
Description
Unit
Through drilling
• Yes
Through drilling with feedrate FD
• No
ZD - (only for
through drilling
"yes")
Depth for feedrate reduction (abs) or depth for feedrate reduction in relation to Z1 (inc) mm
FD - (only for
through drilling
"yes")
Reduced feedrate for through drilling referred to drilling feedrate F
%
Feedrate for through drilling (ShopTurn) mm/min or
mm/rev
Feedrate for through drilling (G code) Distance/min
or dis-
tance/rev
DT - (only for
through drilling
"no")
• Dwell time (at final drilling depth) in seconds
• Dwell time (at final drilling depth) in revolutions
s
rev
Parameters in the "Input simple" mode
G code program parameters
ShopTurn program parameters
Input
• Simple
RP
Retraction plane
mm
T
Tool name
D
Cutting edge number
F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter
Description
Machining
position (only for G
code)
• Single position
Drill hole at programmed position.
• Position pattern
Position with MCALL
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
