Setting up the machine
3.2 Approaching a reference point
Turning
68 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Approaching a reference point
3.2.1
Your machine tool can be equipped with an absolute or incremental path measuring system.
An axis with incremental path measuring system must be referenced after the controller has
been switched on – however, an absolute path measuring system does not have to be
referenced.
For the incremental path measuring system, all the machine axes must therefore first
approach a reference point, the coordinates of which are known to be relative to the machine
zero-point.
Prior to the approach, the axes must be in a position from where they can approach the
reference point without a collision.
The axes can also all approach the reference point simultaneously, depending on the
manufacturer’s settings.
Please refer to the machine manufacturer's specifications.
If the axes are not in a collision-free position, you must first traverse them to safe positions
in "JOG" or "MDI" mode.
You must follow the axis motions directly on the machine!
Ignore the actual value display until the axes have been referenced!
The software limit switches are not active!
Press the <REF. POINT> key.
Select the axis to be traversed.
