Programming technology functions (cycles)
9.5 Contour milling
Turning
544 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
The following parameters are hidden. They are pre-assigned fixed values or values that can
be adjusted using setting data.
PL (only for G
Machining plane
SC (only for G
code)
Safety clearance 1 mm x
Starting point Starting point is automatically calculated - (only for ∇ and
Automatic
Lift mode Lift mode before new infeed - (only for ∇, ∇∇∇ base or ∇∇∇
to RP
Please refer to the machine manufacturer's specifications.
Contour pocket residual material (CYCLE63, option)
Function
When you have removed stock from a pocket (with/without islands) and there is residual
material, then this is automatically detected. You can use a suitable tool to remove this
residual material without having to machine the whole pocket again, i.e. avoiding
unnecessary non-productive motion. Material that remains as part of the finishing allowance
is not residual material.
The residual material is calculated on the basis of the milling cutter used for stock removal.
If you mill several pockets and want to avoid unnecessary tool changeover, remove stock
from all the pockets first and then remove the residual material. In this case, for removing the
residual material, you also have to enter a value for the reference tool TR parameter, which,
for the ShopTurn program, additionally appears when you press the "All parameters" softkey.
When programming, proceed as follows:
1. Contour pocket 1
2. Stock removal
3. Contour pocket 2
4. Stock removal
5. Contour pocket 1
6. Removing residual stock
7. Contour pocket 2
8. Removing residual stock
