Siemens SINUMERIK 828D - Straight and Circular Machining; Straight Turning

Working with Manual Machine
15.5 Simple workpiece machining
Turning
810 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Unit
T
Tool name
D Cutting edge number
ST
F Feedrate mm/min
mm/rev
S / V
Spindle speed or constant cutting rate rev/min
m/min
Spindle M function
Spindle off: Spindle is stopped
CCW rotation: Spindle rotates counterclockwise
CW rotation: Spindle rotates clockwise
Gear stage Specification of the gear stage (auto, I - V)
α1
Rotation of the coordinate system.
Degrees
Other M function Input of machine functions
Refer to the machine manufacturer's table for the correlation between the meaning
and number of the function.
Machining plane Selection of the machining plane (G17(XY), G18 (ZX), G19 (YZ))
15.5.3
Straight and circular machining
15.5.3.1
Straight turning
Use this function for simple, straight machining (e.g. face or longitudinal turning).
Procedure
1.
"Manual Machine" is active.
2.
Press the "Straight circle" softkey.
3.
Select the desired straight machining and press the "All axes" softkey
- OR -
Press the softkey "Straight X α"
