Siemens SINUMERIK 828D User Manual

Managing programs
13.7 Displaying the program in the Preview.
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
751
7.
Press the "Continue search" and "OK" softkeys if the directory or the file
does not correspond to the required result.
- OR -
Press the "
Cancel" softkey when you want to cancel the search.
13.7
Displaying the program in the Preview.
You can show the content on a program in a preview before you start editing.
Procedure
1.
Select the "Program manager" operating area.
2.
Select a storage location and place the cursor on the relevant program.
3.
Press the ">>" and "Preview window" softkeys.
The "Preview: ..." window opens.
4.
Press the "Preview window" softkey again to close the window.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
