Siemens SINUMERIK 828D User Manual

Multi-channel machining
10.2 Multi-channel support
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
619
10.2.3
Entering multi-channel data
In the parameter screen "Multi-channel data", enter the following data, which applies for all
channels for G code and ShopTurn programs:
● Measurement unit
● Work offset (e.g. G54)
● Z value of the work offset (optional)
● Blank
● Spindle chuck data (optional)
● Speed limitation
● Counter-spindle data, if required
● Counter-spindle with/without mirroring (for G code)
Machine manufacturer
If you are working with pure G code programming,
it is possible that the parameter
screen "Multi
-channel data" does not open.
Please refer to the machine manufacturer's instructions.
Parameter
Description
Unit
Measurement unit
Selecting the measurement unit mm
inch
Main spindle
Work offset
Selecting the work offset
Write to the
work offset
• Yes
Parameter ZV is displayed
• No
Parameter ZV is not displayed
ZV Z value of the work offset
For G54, the Z value is entered into the work offset.
Note
:
Please refer to the machine manufacturer's instructions.
Blank
• Tube
• Cylinder
• Polygon
• Centered cuboid
XA
Outside diameter ∅ – for tube and cylinder
mm
XI
Inside diameter (abs) or wall thickness (inc) – only for tube
mm
ZA
Initial dimension
mm
