Multi-channel machining
10.2 Multi-channel support
Turning
620 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Unit
ZI
Final dimension (abs) or final dimension in relation to ZA (inc)
ZB
Machining dimension (abs) or machining dimension in relation to ZA (inc) mm
N
Number of edges – only for polygon
SW or L
Width across flats or edge length – only for polygon mm
W
Width of the blank - only for centered cuboid
mm
L
Length of the blank - only for centered cuboid
mm
S
Speed limitation of the main spindle
rev/min
Spindle chuck
data
• Yes
You enter spindle chuck data in the program.
• No
Spindle chuck data is transferred from the setting data.
Note
:
Please observe the machine manufacturer’s instructions.
Spindle chuck
data
• Only chuck
You enter spindle chuck data in the program.
• Complete
You enter tailstock data in the program.
Note
:
Please observe the machine manufacturer’s instructions.
ZC
• The main spindle chuck dimensions - (only for spindle chuck data "yes")
mm
ZS
• Stop dimension of the main spindle - (only for spindle chuck data "yes")
mm
ZE
• Jaw dimension of the main spindle for jaw type 2 - (only for spindle chuck data
"yes")
mm
Counter-spindle
Spindle chuck data
• Yes
You enter spindle chuck data in the program.
• No
Spindle chuck data is transferred from the setting data.
Note
:
Please observe the machine manufacturer’s instructions.
Spindle chuck data
• Only chuck
You enter spindle chuck data in the program.
• Complete
You enter tailstock data in the program.
Note
:
• Please observe the machine manufacturer’s instructions.
