Siemens SINUMERIK 828D - Page 621

Multi-channel machining
10.2 Multi-channel support
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
621
Parameter
Description
Unit
Jaw type Selecting the jaw type of the counter-spindle. Dimensions of the front edge or stop
edge - (only if spindle chuck data "yes")
• Jaw type 1
• Jaw type 2
ZC
The counter-spindle chuck dimensions - (only for spindle chuck data "yes")
mm
ZS
Stop dimension of the counter-spindle - (only for spindle chuck data "yes")
mm
ZE Jaw dimension of the counter-spindle for jaw type 2 - (only for spindle chuck data
"yes")
mm
XR Tailstock diameter - (only for spindle chuck data "complete" and tailstock that has
been set up)
mm
ZR Tailstock length - (only for spindle chuck data "complete" and tailstock that has
been set up)
mm
Mirroring Z
• Yes
Mirroring is used when machining on the Z axis
• No
Mirroring is not used when machining on the Z axis
Work offset
Selecting the work offset
Write to the
work offset
• Yes
Parameter ZV is displayed
• No
Parameter ZV is not displayed
ZV Z value of the work offset
The value exceeds the Z value in the selected work offset.
Blank
• Tube
• Cylinder
• Polygon
• Centered cuboid
ZA
Initial dimension
mm
ZI
Final dimension (abs) or final dimension in relation to ZA (inc)
mm
ZB
Machining dimension (abs) or machining dimension in relation to ZA (inc)
mm
XA
Outside diameter – (only for tube and cylinder)
mm
XI
Inside diameter (abs) or wall thickness (inc) – (only for tube)
mm
N
Number of edges – (only for polygon)
SW or L Width across flats or edge length – (only for polygon) mm
W
Width of the blank - (only for centered cuboid)
mm
L
Length of the blank - (only for centered cuboid)
mm
S Speed limitation of the counter-spindle rev/min
