Alarm, error and system messages
14.9 Remote diagnostics
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
803
You can permit remote access to your control via a teleservice adapter IE connected at
X127.
r to the machine manufacturer's specifications.
Software option
You need the "MC Informat
ion System RCS Host" option to display the "Per-
ote diagnostics (RCS)" window is opened.
Press the "Permit modem" softkey.
Access to the control via modem is enabled so that a connection can be
established.
ess again, press the "Permit modem" softkey again.
Request remote diagnostics
Using the "Request remote diagnostics" softkey, from your control you have the option of
actively requesting remote diagnostics with your machinery construction OEM.
The access via modem must be enabled if the access is to be made via modem.
refer to the machine manufacturer's specifications.
When requesting remote diagnostics, you obtain a window with the corresponding pre-
assigned data and values of the ping service. If required, you can ask your machine
manufacturer for this data.
IP address IP address of the remote PC
Standard port that is intended for remote diagnostics
Send duration Duration of the request in minutes
Cycle in which the message is sent to the remote PC in seconds
Ping send
Message for the remote PC
