HT 8
19.4 Virtual keyboard
Turning
854 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Softkeys on the machine control panel menu
Available softkeys:
Select the "Machine" operating area
Select the axis feedrate in the variable increment
hange the channel
t-
Switch single block execution on/off
Switch between WCS and MCS
Note
The window will automatically disappear when changing regions areas with the "Menu
Sele
ct" key.
The virtual keyboard is used as the input device for touch operator panels.
It opens when you double-click an operator element with input capability (editor, edit field).
The virtual keyboard can be positioned anywhere on the operator interface. In addition, you
can toggle between a full keyboard and a reduced keyboard that only includes the number
block. Moreover, with the full keyboard, you can toggle between English key assignments
and the keyboard assignment for the current language setting.
Click in the required input field in order to place the cursor there.
The virtual keyboard is displayed.
Enter your values via the virtual keyboard.
Position the cursor on an another operator element.
The value is accepted and the virtual keyboard is closed.
