Multi-channel machining
10.2 Multi-channel support
Turning
658 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Stock removal
Calling up the cycle
Precondition
● "programSYNC" option
The part program or ShopTurn program to be processed has been cr
e-
ated and you are in the editor.
Press the "Contour turning" softkey.
Press the "Stock removal" softkey.
Only those parameters relevant for stock removal with 2 synchronized channels of a
workpiece are subsequently described. All other parameters are described in Chapter
"Contour turning".
Machining
• ∇ 2 CHAN
2-channel roughing
• ∇∇∇ 2 CHAN
Defines whether the currently set channel is the leading or following channel.
All calculations are carried out in the leading channel.
Number
Selecting the number of the partner channel if there are more than 2 channels avail-
able.
• If, for the channel parameter, "Leading channel" is selected, then the channel
number of the following channel must be parameterized here.
• If, for the channel parameter, "Following channel" is selected, then the channel
number of the leading channel must be parameterized here.
DCH
Channel offset
• For positive parameters, then the leading channel machining is executed before
the following channel by the channel offset.
• For a negative parameter, when executing the program, the leading or following
channel property is interchanged.
• If the parameter is equal to zero, then balance cutting (axis coupling) is used.
mm (inch)
