Introduction
2.4 User interface
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
55
2.4.11
Changing the user interface language
Procedure
1.
Select the "Start
-up" operating area.
2.
Press the "Change language" softkey.
The "Language selection" window opens. The language set last is s
e-
lected.
3.
Position the cursor on the desired language.
4.
Press the "OK" softkey.
- OR -
Press the <INPUT> key.
The user interface changes to the selected language.
Note
Changing the language directly on the input screens
You can switch between the user interface languag
es available on the controller directly on
the user interface by pressing the key combination <CTRL + L>.
2.4.12
Entering Chinese characters
2.4.12.1
Function - input editor
Using the input editor IME (input method editor), you can select Asian characters where you
enter the phonetic notation. These characters are transferred into the user interface.
Note
Call the input editor with <Alt + S>
The input editor can only be called there where it is permissible to enter Asian characters.
The editor is available for the following Asian languages:
Simplified Chinese
Traditional Chinese
