Multi-channel machining
10.2 Multi-channel support
Turning
640 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Using the synchronized view, you have the possibility of obtaining an overview of the time
sequence of a program. In this case, program instructions are evaluated to coordinate
channels and are arranged in parallel in the editor view.
As a result of the synchronized view of the programs, you can easily identify at which
locations the programs are synchronized in the various channels.
WAITM Sets a mark and waits for the specified channels (with exact stop)
Sets a mark and waits for the specified channels (without exact stop)
Waits for the end of program of the specified channels
Note
Error identification when synchronizing the programs
The error can only be identified if the appropriate program is displayed. If a WAIT mark
involves a channel to which a program is not assigned in the job list, then this is marked as
having an error.
If you have enabled the synchronized view, then the following symbols are displayed at the
top right in the program title bar:
Synchronized view: Error
Errors were identified after enabling "synchronized view" or new "syn-
chronization" (e.g. WAIT marks not found in other programs).
Synchronized view: checked
No error was detected after enabling "synchronized view" or new "syn-
