Multi-channel machining
10.2 Multi-channel support
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
641
Wait marks can also be used within blocks.
● Closed block
– If there is a WAIT mark within a closed block, the clock of this WAIT mark is displayed
in front of the block name.
In the synchronized view, the closed block is synchronized.
– If there are several WAIT marks within a closed block, then a clock is displayed in
front of the block name. It is yellow, if all clocks of the WAIT marks in the block are
yellow, otherwise it is red.
In the synchronized view, the closed block is synchronized to the last WAIT mark in
the block.
● Opened block
– If there is a WAIT mark, the clock is displayed in front of the WAIT mark.
In front of the WAIT mark, the clock is displayed in either yellow or red. The program is
synchronized at the WAIT mark.
– If there are several WAIT marks, the clocks are displayed in either yellow or red at the
WAIT marks. The program is synchronized at the WAIT marks.
Determining program runtimes
After a simulation, the required processing time for the program blocks is displayed in the
editor. For multi-channel programs, the delay time is displayed at the wait points.
Spindle transfer between the channels
If you use the spindles alternating in several channels (e.g. main and counterspindle), then it
may be necessary to exit the active plane "Face C" (TRANSMIT) or "Peripheral C"
(TRACYL):
Press the menu forward key and the "Straight/Circle" softkey.
Press the "Tool" softkey.
In the "Plane selection" field, select the "Turning" setting
(TRAFOOF).
