Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.1 Drilling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
341
Parameter
Description
Unit
X0
C0
Y0
Z0
Y1
...Y7
Z1
...Z7 (only for ShopTurn
Peripheral surface Y:
Reference point in X direction (abs)
Positioning angle for machining surface
Y coordinate of 1st position (abs)
Z coordinate of 1st position (abs)
Y coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated
Z coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated
mm
Degrees
mm
mm
mm
mm
9.1.12
Row position pattern (HOLES1)
Function
You can program any number of positions at equal distances along a line using the "Row
position pattern" function.
Procedure
1.
The part program or ShopTurn program to be
processed has been cre-
ated and you are in the editor.
2.
Press the "Drilling" softkey.
3.
Press the "Positions" and "Row" softkeys.
The "Position row" input window opens.
Parameter
Description
Unit
LAB
(only for G code)
Repeat jump label for position
PL
(only for G code)
Machining plane
Machining
surface
(only for Shop-
Turn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
