Programming technology functions (cycles)
9.1 Drilling
Turning
306 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Deep-hole drilling 1 (CYCLE83)
Function
With the "Deep-hole drilling 1" cycle, the tool is inserted in the workpiece with the
programmed spindle speed and feedrate in several infeed steps until the depth Z1 is
reached. The following can be specified:
● Number of infeed steps constant or decreasing (via programmable degression factor)
● Chip breaking without lifting or swarf removal with tool retraction
● Feedrate factor for 1st infeed to reduce the feedrate or increase the feedrate (e.g. if a
hole has already be predrilled)
● Dwell times
● Depth in relation to drill shank of drill tip
For ShopTurn, the "Clamp spindle" function can be set up by the machine manufacturer.
Please refer to the machine manufacturer's specifications.
For simple machining operations, you have the option to reduce the wide variety of
parameters to the most important parameters using the "Input" selection field. In this "Input
simple" mode, the hidden parameters are allocated a fixed value that cannot be adjusted.
Various defined values can be pre
-assigned using setting data.
Please refer to the machine manufacturer's specifications.
If the workpiece programming requires it, you can display and change all of the parameters
using "Input complete".
