Multi-channel machining
10.1 Multi-channel view
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
615
Note
2-channel display
Unlike the smaller operator panels, the T,F,S window i
s visible for a 2-channel view in the
"Machine" operating area.
Program operating area
You can display as many as ten programs next to each other in the editor.
Displaying a program
You can define the width of the program in the Editor window using the settings in the editor.
This means that you can distribute programs evenly - or you can widen the column with the
active program .
Channel status
When required, channel messages are displayed in the status display.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
10.1.3
Setting the multi-channel view
Setting
Meaning
View Here, you specify how many channels are displayed.
• 1 channel
• 2 channels
• 3 channels
• 4 channels
Channel selection and
sequence
(for "2 - 4 channels"
view)
You specify which channels in which sequence are displayed in the multi-
channel view.
Visible
(for "2 - 4 channels"
view)
Here, you specify which channels are displayed in the multi-channel view.
You can quickly hide channels from the view.
