Specifically jump to the program block
If you notice anything peculiar in the graphic or identify an error, then from this location, you
can directly jump to the program block involved to possibly edit the program.
Requirements
● The required program is opened in the mold making view.
● The "Graphic" softkey is active.
Procedure
1.
Press the ">>" and "Select point" softkeys.
Cross
-hairs for selecting a point are shown in the diagram.
2.
Using the cursor keys, move the cross
-hairs to the appropriate position
in the graphic.
3
.
Press the "Select NC block" softkey.
The cursor jumps to the associated program block in the editor.
5.13.4
Searching for program blocks
Using the "Search" function, you can search for specific program blocks as well as edit
programs; you can do this in one step by replacing the text that you are searching for by a
new text.
Precondition
● The required program is opened in the mold making view.
● The "NC blocks" softkey is active.
Procedure
1.
Press the "Search" softkey.
A new vertical softkey bar appears.
See also
Searching in programs (Page 145)
Replacing program text (Page 146)
