Programming technology functions (cycles)
9.5 Contour milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
545
Software option
For removing residual stock, you requir
e the option "residual stock detection
and machining".
Clamping the spindle
For ShopTurn, the "Clamp spindle" function can be set up by the machine manufacturer.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
See also
Clamping the spindle (Page 247)
Procedure
1.
The part program or ShopTurn program to be processed has been cr
e-
ated and you are in the editor.
2.
Press the "Milling", "Contour milling" and "Pocket resid. mat." softkeys.
The "Pocket Res. Mat." input window opens.
3.
For the ShopTurn program, press the "All parameters" softkey if you
want to
enter additional parameters.
Parameters, G code program
Parameters, ShopTurn program
PRG Name of the program to be generated T Tool name
PL
Machining plane D Cutting edge number
Milling direction
• Climbing
• Conventional
F
Feedrate mm/min
mm/tooth
RP Retraction plane mm S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
SC
Safety clearance
mm
F
Feedrate
mm/min
