Programming technology functions (cycles)
9.5 Contour milling
Turning
546 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
parameters
Description
Unit
Machining
surface
(only for Shop-
Turn)
• Face C
• Face Y
• Face B
• Peripheral surface C
• Peripheral surface Y
(only for Shop-
Turn)
Clamp/release spindle (only for end face Y/B and peripheral surface Y)
The function must be set up by the machine manufacturer.
TR Reference tool Tool, which is used in the "stock removal" machining step. This is used
to determine the residual corners.
D
Cutting edge number
Z0
Reference point in the tool axis Z
mm
Z1
Pocket depth (abs) or depth referred to Z0 or X0 (inc)
mm
CP Positioning angle for machining area
- (only for ShopTurn, machining surface, face Y)
Degrees
C0 Positioning angle for machining surface
- (only for ShopTurn, machining surface, peripheral surface Y)
Degrees
DXY
• Maximum plane infeed
• Maximum plane infeed as a percentage of the milling cutter diameter
mm
%
DZ
Maximum depth infeed
Lift mode
Lift mode before new infeed
If the machining operation requires several points of insertion, the retraction height can
be programmed:
• To retraction plane
• Z0 + safety clearance
When making the transition to the next insertion point, the tool returns to this height. If
there are no elements larger than Z0 (X0) in the pocket area, then Z0 (X0) + safety
clearance can be programmed as the lift mode.
mm
mm
