Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.1 Drilling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
295
Procedure
1.
The part program or ShopTurn program to be processed has been cr
e-
ated and you are
in the editor.
2.
Press the "Drilling" softkey.
3.
Press the "Centering" softkey.
The "Centering" input window opens.
Parameters, G code program
Parameters, ShopTurn program
PL
Machining plane
T
Tool name
RP
Retraction plane
mm
D
Cutting edge number
SC Safety clearance mm F
Feedrate mm/min
mm/rev
S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
Parameter
Description
Unit
Machining posi-
tion
(only for G
code)
• Single position
Drill hole at programmed position
• Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
Machining
surface
(only for Shop-
Turn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for Shop-
Turn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for Shop-
Turn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
