Machining the workpiece

5.4 Displaying the current program block

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

127

Machine manufacturer

Please refer to the machine

manufacturer's specifications.

Procedure

A program is selected for execution and has been opened in the "M

chine" operating area.

Press the "Basic blocks" softkey.

The "Basic Blocks" window opens.

Press the <SINGLE BLOCK> key if you wish to execute the program

block

-by-block.

Press the <CYCLE START> key to start the program execution.

The axis positions to be approached, modal G functions, etc., are di

played in the "Basic Blocks" window for the currently active pr

ogram

block.

Press the "Basic blocks" softkey once again to hide the window again.
