Machining the workpiece

5.9 Overstore

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

141

Skip levels, activate

Select the corresponding checkbox to activate the desired skip level.

Note

The "Program Control

- Skip Blocks" window is only available when more than one skip level

is set up.

Procedure

Select the "Machine" operat

ing area.

Press the <AUTO> or <MDA> key.

Press the "Prog. ctrl." and "Skip blocks" softkeys.

The "Progra

m Control" window appears and shows a list of skip levels.
