Machining the workpiece
5.16 Working with DXF files
Turning
190 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Size (for position pattern "Row", "Frame", "Grid")
Once the reference point and clearances have been specified, press the
"Select element" softkey repeatedly.
All expansions of the frame or the grid are displayed.
Press the "Accept element" softkey to confirm the selected frame or grid.
If all elements for the position row or position frame and position grid are
valid, the drilling positions are displayed with blue points.
Circle direction (for circle and partial circle)
Once the reference point and clearance have been specified, press the
"Select element" softkey repeatedly.
The displayed circle is shown in the possible orientations.
Press the "Select element" softkey to confirm the selected circle or pa
r-
If all elements of the circle or partial circle are valid, the d
rilling positions
are displayed with blue points.
o reset the last actions.
Transfer drilling positions to the cycle and to the program
Press the "OK" softkey in order to accept the position values.
You return to the associated parameter screen form.
Press the "Accept" softkey to transfer the drilling positions to the pr
o-
Operation with keyboard and mouse
In addition to the operation using the softkeys, you can also operate the functions with the
keyboard and the mouse.
