Simulating machining
6.1 Overview
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
197
Note
Tool display in the simulation and for simultaneous recording
In order that workpiece simulation is also possible for tools that have either not been
measured or have been incompl
etely entered, certain assumptions are made regarding
For instance, the length of a miller or drill is set to a value proportional to the tool radius
so that cutting can be simulated.
Note
Thread turns are not displayed
For thread a
nd drill and thread milling, the thread turns are not displayed in the simulation
and for simultaneous recording.
You can choose between three variants of graphical display:
● Simulation before machining of the workpiece
Before machining the workpiece on the machine, you can perform a quick run-through in
order to graphically display how the program will be executed.
● Simultaneous recording before machining of the workpiece
Before machining the workpiece on the machine, you can graphically display how the
program will be executed during the program test and dry run feedrate. The machine
axes do not move if you have selected "no axis motion".
● Simultaneous recording during machining of the workpiece
You can follow machining of the workpiece on the screen while the program is being
executed on the machine.
The following views are available for all three variants:
● Side view
● Half section
● Front view
● 3D view
● 2-window
