Siemens SINUMERIK 828D - Page 207

Simulating machining
6.7 Editing the simulation display
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
207
Parameter
Description
Unit
Counterspindle
Mirroring Z
• Yes
Mirroring is used when machining on the Z axis
• No
Mirroring is not used when machining on the Z axis
Blank
Selecting the blank
• Centered cuboid
• Tube
• Cylinder
• Polygon
• without
XA Outside diameter ∅ - (only for tube and cylinder)
XI Inside diameter (abs) or wall thickness (inc) – (only for tube) mm
W
Width of the blank - (only for centered cuboid)
N
Number of edges – (only for polygon)
L
Length of the blank - (only for centered cuboid)
mm
SW or L Width across flats or edge length – (only for polygon) mm
ZI
Blank length (inc)
mm
ZB
Machining dimension (ink)
mm
Procedure
1.
The simulation or the simultaneous recording is started.
2.
Press the ">>" and "Blank" softkeys.
The "Blank Input" windows opens and display
s the pre-assigned values.
3.
Enter the desired values for the dimensions.
4.
Press the
"Accept" softkey to confirm your entries. The newly defined
workpiece is displayed.
