Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.1 Drilling
Turning
308 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameters in the "Input complete" mode
G code program parameters
ShopTurn program parameters
Input
• Complete
PL
Machining plane T Tool name
RP
Retraction plane
mm
D
Cutting edge number
SC Safety clearance mm F
Feedrate mm/min
mm/rev
S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
Parameter
Description
Unit
Machining posi-
tion
(only for G
code)
• Single position
Drill hole at programmed position
• Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
Machining
surface
(only for Shop-
Turn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for Shop-
Turn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for Shop-
Turn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Machining
• Swarf removal
The drill is retracted from the workpiece for swarf removal.
• Chip breaking
The drill is retracted by the retraction distance V2 for chip breaking.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
