Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.1 Drilling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
319
Parameter
Description
Unit
ZD - (only for
through drilling
"yes")
Depth for feedrate reduction (abs) or depth for feedrate reduction in relation to Z1
(inc).
mm
FD - (only for
through drilling
"yes")
Feedrate for through drilling referred to drilling feedrate F. %
Feedrate for through drilling (ShopTurn).
mm/min or mm/rev.
Feedrate for through drilling (G code). distance/min or
distance/rev
DT - (only for
through drilling
"no")
• Dwell time at final depth in seconds
• Dwell time at final depth in revolutions
s
U
Retraction
• Retraction to pilot hole depth
• Retraction to retraction plane
FR
Retraction in rapid traverse
Direction of
spindle rotation
during retrac-
tion
•
Retraction with stationary spindle
•
•
SR / VR
(only for select-
ed spindle
direction of
rotation)
• Spindle speed for retraction referred to the drilling speed
• Spindle speed for retraction
• Constant cutting rate VR for retraction
%
rpm
m/min
Coolant off -
(only G code)
M function to switch off the coolant
Parameters in the "Input simple" mode
G code program parameters
ShopTurn program parameters
Input
• simple
RP Retraction plane mm T Tool name
D
Cutting edge number
F Feedrate mm/min
mm/rev
F Feedrate mm/min
mm/rev
S / V Spindle speed or con-
stant cutting rate
rpm
m/min
S / V Spindle speed or constant
cutting rate
rpm
m/min

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
