Programming technology functions (cycles)
9.1 Drilling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
345
Parameter
Description
Unit
αX
αY
L1
L2
N1
N2
Shear angle X
Shear angle Y
Distance between columns
Distance between rows
Number of columns
Number of rows
Degrees
Degrees
mm
mm
Parameter
Description
Unit
LAB
(only for G code)
Repeat jump label for position
PL
(only for G code)
Machining plane
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
X0
Y0
α0
(only for G Code)
X coordinate of the reference point X (abs)
This position must be programmed absolutely in the 1st call.
Y coordinate of the reference point Y (abs)
This position must be programmed absolutely in the 1st call.
Angle of rotation of the line referred to the X axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
mm
Degrees
Z0
X0
Y0
α0
(only for ShopTurn)
Face C:
Z coordinate of the reference point (abs)
X coordinate of the reference point – first position (abs)
Y coordinate of the reference point – first position (abs)
Angle of rotation of line in relation to the X axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
mm
mm
Degrees
Z0
CP
X0
Y0
α0
(only for ShopTurn)
Face Y:
Z coordinate of the reference point (abs)
Positioning angle for machining area
X coordinate of the reference point – first position (abs)
Y coordinate of the reference point – first position (abs)
Angle of rotation of line in relation to the X axis
Positive angle: Line is rotated counter-clockwise.
Negative angle: Line is rotated clockwise.
mm
Degrees
mm
mm
Degrees
