Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.2 Rotate
Turning
362 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameters
Description
Unit
Position
Form E machining position:
Undercut size according to DIN table:
E.g.: E1.0 x 0.4 (undercut form E)
X0
Reference point X ∅
mm
Z0
Reference point Z
mm
X1
Allowance in X ∅ (abs) or allowance in X (inc) mm
VX
Cross feed ∅ (abs) or cross feed (inc) mm
* Unit of feedrate as programmed before the cycle call
Parameters, G code program (undercut, form F)
Parameters, ShopTurn program (undercut, form F)
PL
Machining plane
T
Tool name
SC
Safety clearance
mm
D
Cutting edge number
F
Feedrate
*
F
Feedrate
mm/rev
S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
Parameters
Description
Unit
Position
Form F machining position:
Undercut size according to DIN table:
e.g.: F0.6 x 0.3 (undercut form F)
X0
Reference point X ∅
mm
Z0
Reference point Z
mm
