Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.2 Rotate
Turning
364 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameters, G code program
(undercut, thread DIN)
Parameters, ShopTurn program
(undercut, thread DIN)
PL
Machining plane
T
Tool name
SC Safety clearance mm D Cutting edge number
F
Feedrate
*
F
Feedrate
mm/rev
S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
Parameters
Description
Unit
Machining
• ∇ (roughing)
• ∇∇∇ (finishing)
• ∇ + ∇∇∇ (roughing and finishing)
Position
Machining position:
Machining
direction
• Longitudinal
• Parallel to the contour
Form
• Normal (form A)
• Short (form B)
P
Thread pitch (select from the preset DIN table or enter)
mm/rev
X0
Reference point X ∅
mm
Z0
Reference point Z
mm
α
Insertion angle
Degrees
VX
Cross feed ∅ (abs) or cross feed (inc) - (only for ∇∇∇ and ∇ + ∇∇∇)
mm
D
Maximum depth infeed – (only for ∇ and ∇ + ∇∇∇)
mm
U or UX Finishing allowance in X or finishing allowance in X and Z – (only for ∇ and ∇ +
∇∇∇)
mm
UZ
Finishing allowance in Z – (only for UX, ∇ and ∇ + ∇∇∇)
mm
* Unit of feedrate as programmed before the cycle call
