Introduction
2.3 Machine control panels
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
39
Operating modes, machine functions
<JOG>
Select "JOG" mode.
<TEACH IN>
Select "Teach In" submode.
<MDI>
Select "MDI" mode.
<AUTO>
Select "AUTO" m
ode.
<REPOS>
Repositions, re
-approaches the contour.
<REF POINT>
Approach reference point.
Inc <VAR>
(Incremental Feed Variable)
Incremental mode with variable increment size.
...
Inc
(incremental feed)
Incremen
tal mode with predefined increment size of 1, ..., 10000 incre-
ments.
Machine manufacturer
A machine data code defines how the incremen
t value is in-
terpreted.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
