Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.3 Contour turning
Turning
398 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameters
Description
Unit
Form F Undercut size
e.g. F0.6x0.3
DIN thread P
α
Thread pitch
Insertion angle
mm/rev
Degrees
Thread Z1
Z2
R1
R2
T
Length Z1
Length Z2
Radius R1
Radius R2
Insertion depth
mm
mm
mm
mm
mm
Chamfer
FS
Transition to following element - chamfer
mm
CA Grinding allowance
•
Grinding allowance to right of contour
•
Grinding allowance to left of contour
mm
Additional commands
Additional G code commands
Contour element "Straight line e.g. ZX"
Parameters
Description
Unit
Z
End point Z (abs or inc)
mm
X
End point X ∅ (abs) or end point X (inc)
mm
α1
Starting angle to Z axis
Degrees
α2
Angle to the preceding element
Degrees
Transition to next ele-
ment
Type of transition
• Radius
• Chamfer
Radius
R
Transition to following element - radius
mm
Chamfer
FS
Transition to following element - chamfer
mm
CA Grinding allowance
•
Grinding allowance to right of contour
•
Grinding allowance to left of contour
mm
Additional commands
Additional G code commands

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
