Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
469
Note
A multi
-edge with more than two edges is traversed helically; with a single or double
edge, each edge is machined separately.
Procedure
1.
The part program or ShopT
urn program to be processed has been cre-
ated and you are in the editor.
2.
Press the "Mill
ing" softkey.
3.
Press the "Multi
-edge spigot" and "Multi-edge" softkeys.
The "Multi
-edge" input window opens.
Parameters in the "Input complete" mode
Parameters, G code program
Parameters, ShopTurn program
Input
• Complete
PL
Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F
Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
F
Feedrate
*
