Programming technology functions (cycles)
9.4 Milling
Turning
480 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face C
: The positions refer to the reference point:
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
mm
mm or
degrees
mm
CP
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face Y
: The positions refer to the reference point:
Positioning angle for machining area
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only for ShopTurn)
Peripheral surface C
: The positions refer to the reference point:
Reference point Y or reference point angle polar
Reference point Z
Cylinder diameter ∅
mm or
degrees
mm
mm
C0
Y0
Z0
X0
(only for ShopTurn)
Peripheral surface Y
: The positions refer to the reference point:
Positioning angle for machining surface
Reference point Y
Reference point Z
Reference point X
Degrees
mm
mm
mm
W
Slot width
mm
L
Slot length
mm
Z1
Slot depth (abs) or depth referred to Z0 or X0 (inc) - (only for ∇ and ∇∇∇)
mm
DXY
(only for ShopTurn)
• Maximum plane infeed
• Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇ and ∇∇∇)
mm
%
DZ
Maximum depth infeed – (only for ∇ and ∇∇∇)
mm
UXY Plane finishing allowance for the length (L) and width (W) of the slot (only for ∇
and ∇∇∇).
mm
UZ
Depth finishing allowance (tool axis) - (only for ∇ and ∇∇∇)
mm
