Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
505
Table 9- 1
Parameters, G code program
Parameters, ShopTurn program
PL
Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F
Feedrate mm/min
mm/rev
SC Safety clearance mm S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
F
Feedrate
mm/min
Parameter
Description
Unit
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for ShopTurn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Machining
• ∇ (roughing)
• ∇∇∇ (finishing)
Machining direction:
• Z0 → Z1
Machining from top to bottom
• Z1 → Z0
Machining from bottom to top
Direction of rotation of the thread:
• Right-hand thread
A right-hand thread is cut.
• Left-hand thread
A left-hand thread is cut.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
